171. Download the architectural drawings of the 8-storey Majestic Hotel with a total floor area of 22,400 m2
- File format: .DWG
- Size: 3.91 MB
From a professional standpoint, the Majestic Hotel’s architectural documentation is a benchmark set of drawings, showcasing a sophisticated blend of Neoclassical language and high-end hotel spatial planning.
Spanning a total floor area of 22,400 m2, the floor plans from the ground level to the rooftop are organized with exceptional functional logic. The Ground Floor exudes grandeur with a vast reception lobby, integrating functional zones such as the Coffee Lounge and commercial areas with seamless circulation. A highlight is the first-floor plan, featuring a central swimming pool that acts as an architectural “breathing space” and provides a premium vantage point for internal suites.
Regarding the elevations, the design skillfully balances the rhythm of solids and voids. Ionic columns running along the facade, combined with arched openings at the podium and ornate wrought-iron balconies, evoke a timeless heritage aesthetic. Furthermore, the sections provide a detailed breakdown of vertical circulation (elevators, staircases) and floor heights, reflecting meticulous engineering and fire safety integration.
This high-quality set of drawings not only adheres to rigorous technical standards but also perfectly preserves the luxurious essence of an iconic Saigon landmark.
